Water Dewpoint Analyzer

By ZEGAZ

WDP5000™ is the only analyzer designed for the first-principle detection of moisture dewpoint in natural gas. Most other analyzers measure moisture content at low pressure and then estimate water dewpoint at a higher pressure. WDP5000™ uses a novel implementation of chilled-mirror technology to accurately and unambiguously detect the water dewpoint at the supplied pressure. It can handle pressures up to 2000 psig (137 barg) eliminating the need to reduce the pressure, thus avoiding errors associated with pressure regulation.

Documents

Datasheet Manual

Certifications

CSA Cl 1, Div 1, B,C,D

Fantastic Features

True dewpoint measurement.

Works at line pressure.

No moving parts and self-cleaning.

Accurate and unambiguous.

No carrier gas or replacement parts required.

Sensor is not damaged by contaminants, slugs, or aerosols

Amazing Applications

Natural gas pipeline quality control for water dewpoint.

Boiler and gas turbine protection through measurement of water dewpoint.

Monitoring chemical plant inlet of hydrocarbon streams for dewpoint protection.
